Solid geometry: Book 11 Proposition 38

Translations

Ἐὰν κύβου τῶν ἀπεναντίον ἐπιπέδων αἱ πλευραὶ δίχα τμηθῶσιν, διὰ δὲ τῶν τομῶν ἐπίπεδα ἐκβληθῇ, ἡ κοινὴ τομὴ τῶν ἐπιπέδων καὶ ἡ τοῦ κύβου διάμετρος δίχα τέμνουσιν ἀλλήλας. Κύβου γὰρ τοῦ ΑΖ τῶν ἀπεναντίον ἐπιπέδων τῶν ΓΖ, ΑΘ αἱ πλευραὶ δίχα τετμήσθωσαν κατὰ τὰ Κ, Λ, Μ, Ν, Ξ, Π, Ο, Ρ σημεῖα, διὰ δὲ τῶν τομῶν ἐπίπεδα ἐκβεβλήσθω τὰ ΚΝ, ΞΡ, κοινὴ δὲ τομὴ τῶν ἐπιπέδων ἔστω ἡ ΥΣ, τοῦ δὲ ΑΖ κύβου διαγώνιος ἡ ΔΗ. λέγω, ὅτι ἴση ἐστὶν ἡ μὲν ΥΤ τῇ ΤΣ, ἡ δὲ ΔΤ τῇ ΤΗ. Ἐπεζεύχθωσαν γὰρ αἱ ΔΥ, ΥΕ, ΒΣ, ΣΗ. καὶ ἐπεὶ παράλληλός ἐστιν ἡ ΔΞ τῇ ΟΕ, αἱ ἐναλλὰξ γωνίαι αἱ ὑπὸ ΔΞΥ, ΥΟΕ ἴσαι ἀλλήλαις εἰσίν. καὶ ἐπεὶ ἴση ἐστὶν ἡ μὲν ΔΞ τῇ ΟΕ, ἡ δὲ ΞΥ τῇ ΥΟ, καὶ γωνίας ἴσας περιέχουσιν, βάσις ἄρα ἡ ΔΥ τῇ ΥΕ ἐστιν ἴση, καὶ τὸ ΔΞΥ τρίγωνον τῷ ΟΥΕ τριγώνῳ ἐστὶν ἴσον καὶ αἱ λοιπαὶ γωνίαι ταῖς λοιπαῖς γωνίαις ἴσαι: ἴση ἄρα ἡ ὑπὸ ΞΥΔ γωνία τῇ ὑπὸ ΟΥΕ γωνίᾳ. διὰ δὴ τοῦτο εὐθεῖά ἐστιν ἡ ΔΥΕ. διὰ τὰ αὐτὰ δὴ καὶ ἡ ΒΣΗ εὐθεῖά ἐστιν, καὶ ἴση ἡ ΒΣ τῇ ΣΗ. καὶ ἐπεὶ ἡ ΓΑ τῇ ΔΒ ἴση ἐστὶ καὶ παράλληλος, ἀλλὰ ἡ ΓΑ καὶ τῇ ΕΗ ἴση τέ ἐστι καὶ παράλληλος, καὶ ἡ ΔΒ ἄρα τῇ ΕΗ ἴση τέ ἐστι καὶ παράλληλος. καὶ ἐπιζευγνύουσιν αὐτὰς εὐθεῖαι αἱ ΔΕ, ΒΗ: παράλληλος ἄρα ἐστὶν ἡ ΔΕ τῇ ΒΗ. ἴση ἄρα ἡ μὲν ὑπὸ ΕΔΤ γωνία τῇ ὑπὸ ΒΗΤ: ἐναλλὰξ γάρ: ἡ δὲ ὑπὸ ΔΤΥ τῇ ὑπὸ ΗΤΣ. δύο δὴ τρίγωνά ἐστι τὰ ΔΤΥ, ΗΤΣ τὰς δύο γωνίας ταῖς δυσὶ γωνίαις ἴσας ἔχοντα καὶ μίαν πλευρὰν μιᾷ πλευρᾷ ἴσην τὴν ὑποτείνουσαν ὑπὸ μίαν τῶν ἴσων γωνιῶν τὴν ΔΥ τῇ ΗΣ: ἡμίσειαι γάρ εἰσι τῶν ΔΕ, ΒΗ: καὶ τὰς λοιπὰς πλευρὰς ταῖς λοιπαῖς πλευραῖς ἴσας ἕξει. ἴση ἄρα ἡ μὲν ΔΤ τῇ ΤΗ, ἡ δὲ ΥΤ τῇ ΤΣ. Ἐὰν ἄρα κύβου τῶν ἀπεναντίον ἐπιπέδων αἱ πλευραὶ δίχα τμηθῶσιν, διὰ δὲ τῶν τομῶν ἐπίπεδα ἐκβληθῇ, ἡ κοινὴ τομὴ τῶν ἐπιπέδων καὶ ἡ τοῦ κύβου διάμετρος δίχα τέμνουσιν ἀλλήλας: ὅπερ ἔδει δεῖξαι.

If the sides of the opposite planes of a cube be bisected, and planes be carried through the points of section, the common section of the planes and the diameter of the cube bisect one another. For let the sides of the opposite planes CF, AH of the cube AF be bisected at the points K, L, M, N, O, Q, P, R, and through the points of section let the planes KN, OR be carried; let US be the common section of the planes, and DG the diameter of the cube AF. I say that UT is equal to TS, and DT to TG. For let DU, UE, BS, SG be joined. Then, since DO is parallel to PE, the alternate angles DOU, UPE are equal to one another. [I. 29] And, since DO is equal to PE, and OU to UP, and they contain equal angles, therefore the base DU is equal to the base UE, the triangle DOU is equal to the triangle PUE, and the remaining angles are equal to the remaining angles; [I. 4] therefore the angle OUD is equal to the angle PUE. For this reason DUE is a straight line. [I. 14] For the same reason, BSG is also a straight line, and BS is equal to SG. Now, since CA is equal and parallel to DB, while CA is also equal and parallel to EG, therefore DB is also equal and parallel to EG. [XI. 9] And the straight lines DE, BG join their extremities; therefore DE is parallel to BG. [I. 33] Therefore the angle EDT is equal to the angle BGT, for they are alternate; [I. 29] and the angle DTU is equal to the angle GTS. [I. 15] Therefore DTU, GTS are two triangles which have two angles equal to two angles, and one side equal to one side, namely that subtending one of the equal angles, that is, DU equal to GS, for they are the halves of DE, BG; therefore they will also have the remaining sides equal to the remaining sides. [I. 26] Therefore DT is equal to TG, and UT to TS.
